Product Description
- Made of stainless steel
- Measurement: Bevel on end preparation(Range: 37.5°, Accuracy: ±1° )
- Measurement: Pipe wall thickness (Range: 0-45mm(0 – 1-3/4 inch), Graduation: 1mm(1/16 inch), Accuracy: ±0.5mm)
- Measurement: Internal misalignment (Range: 0-35mm(0 – 1-3/8 inch), Graduation: 1mm(1/32 inch), Accuracy: ±0.5mm)
- Measurement: Fit-up gap (Range: 1.6mm,2.4mm, Accuracy: ±0.1mm)
- Measurement: Crown height (Range: 0-35mm(0 – 1-3/8 inch), Graduation: 1mm(1/32 inch), Accuracy: ±0.5mm)
- Measurement: Distance between two marking lines of socket weld (Range: 0-60mm(0 – 2-3/8 inch), Graduation: 1mm(1/16 inch), Accuracy: ±0.5mm)
- Measurement: Fillet weld length (Range: 0-30mm(0 – 1-1/4 inch), Graduation: 1mm(1/16 inch), Accuracy: ±0.5mm)
- Measurement: Fillet weld height (Range: 0-35mm(0 – 1-3/8 inch), Graduation: 1mm(1/32 inch), Accuracy: ±0.5mm)
